Customized Permanent Hard Injection Molded Magnet 310 KA/M HCB IATF 16949

Negotiable
MOQ
Negotiable
Price
Customized Permanent Hard Injection Molded Magnet 310 KA/M HCB IATF 16949
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Injection Molded Magnet
Specification: Permanent
Trademark: JOINT-MAG Magnetic Materials
Processing Service: Bending, Welding, Decoiling, Cutting, Punching, Moulding
Magnetization Direction: Axial Or Diametrical
Model: JC-Y3932, JC-Y4127, JC-Y4231
Highlight:

Injection Molded Magnet 310 KA/M

,

HCB Injection Molded Magnet

,

IATF 16949 Hard Ferrite Magnets

Basic Infomation
Place of Origin: Sichuan, China (Mainland)
Brand Name: JOINT-MAG
Certification: IATF 16949
Model Number: OEM
Payment & Shipping Terms
Packaging Details: Carton Wood Pallet According To Requirements
Payment Terms: L/C, T/T
Supply Ability: 5000T Annual Capacity
Product Description

Customized Permanent Hard Injection Molded Magnet 310 KA/M HCB IATF 16949

Product Description

Injection molded magnets are made by injecting special pellets into a mold. This magnet has the extensive properties of a bonded magnet, including heat resistance. Injection molding technology offers flexibility in shape design, as well as overmolding and insert molding with other parts for easy assembly.


Injection Magnets Advantages
With such isotropic magnets, any magnetization direction can be applied. This is the inherent advantage of making multi-pole magnets.
Injection-molded magnets have excellent dimensional accuracy and mass production capabilities.
Thin wall thicknesses and complex shapes can be fabricated.
Overmolding and insert molding with other parts such as rear yokes, hubs, axles is readily available and injection of other polymer parts can also be added.
The volume fraction of polyester binder is higher in injection molded magnets than in compression molded magnets. It will provide adequate corrosion protection without coating in most applications.



Materials

Made of SrO. 6Fe2O3 and other trace element.
Strontium ferrite powders have been designed to produce all grades of hard ferrite. We will produce high quality products by adding appropriate additives in the powder. Our strict quality control system ensures that the quality is stable and reliable.
Available product styles: curved, fanned, block

Specifications

Injection Molded Magnet
Based on JC-Y3932, JC-Y4127, JC-Y4231 Materials

Magnet info
Materials Permanent Ferrite Magnet
Shapes Sheet, Disc,disk,cylinder,block,ring,bar and customized
Size Length x Width x Thickness You could choose freely according to your plan.
Type Hard
Quality Our expert quality control department ensures magnets are high quality.
Magnetic property

Br can reach 430 KA/m Hcb can reach 310 KA/m,

Hcj can reach 395 KA/m (BH)max can reach 3.6 kJ/m3

color charcoal gray
Grade JC-Y3932; JC-Y3939; JC-Y4041; JC-Y4127; JC-Y4231; JC-Y3744; JC-Y3849; JC-Y4240 etc...



Packaging & Delivery

     Packaging Details: Carton,Wooden Pallet
     Special Package according to your requirements

     Delivery Time: 7-15 days or according to the order


About Us

In October 2004, It was conferred with High-tech Product Certificate, awarded as a “High-tech Enterprises in Sichuan” by Sichuan Provincial Science and Technology Department in December 2004, and “First Price of Sichuan SME Technology Innovation Award” in December 2004. In July 2004, our new JC-Y4240 performance (equivalent to Japan’s TDK FN6B performance level) of ferrite permanent technology was identified and approved by the experts from Science and Technology Department of the Sichuan Province. The declared High Performance Ferrite Permanent Magnet (JC4545)has been listed among Key Science and Technological Program of Sichuan Province and has been given financial support. In 2007,Technology of manufacturing high-performance ferrite permanent magnet with YF30 pre-sintering materials ” were awarded with the tile of Outstanding Technical Achievements and Outstanding Products by the National Materials and Devices industry associations.
