Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949

Negotiable
MOQ
Negotiable
Price
Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Ferrite Magnet
Transport Package: Customized Cartons And Pallets
Specification: ISO/TS16949
Trademark: Joint-Mag
Application: Industrial Magnet
Shape: Magnet Tile, Arc, Segment,Block,Sheet,other According To Your Requirements
High Light:

Ferrite Bar Magnets Corrosion proof

,

permanent bar magnets OEM

,

permanent magnet bar ISO/TS16949

Basic Infomation
Place of Origin: Sichuan, China (Mainland)
Brand Name: JOINT-MAG
Certification: IATF 16949
Model Number: OEM
Payment & Shipping Terms
Packaging Details: Carton Wood Pallet According To Requirements
Payment Terms: T/T
Supply Ability: 5000T Annual Capacity
Product Description

Generator Permanent Ferrite Bar Magnets Customized High Anti Corrosion



Product Description

Permenant  Ferrite Magnets' outstanding properties



1) High performance:

JC-Y3932; JC-Y3939; JC-Y4041; JC-Y4127; JC-Y4231; JC-Y3744; JC-Y3849; JC-Y4240 JC-Y4350 etc (The grade like JC-Y4350&JC-Y3849, JC-Y4240could meet requirements on strong power).
2) High working temperature:

The JC-Y4350 series with 4800-5150 Oe super-high coercive force can replace NdFeB magnets with much lower price.

3) High consistency:

The Br and Hcj of surface magnetic field and magnetic flux can be controlled with +/-1%.

4) High Anti-corrosion:

The sale spray test and humid heat test of the high anti-corrosion coating could be more than 800 hours

5) Low weight loss:

The average low weight loss is less than 10 mg/cm2 in 20 days.

Pros: Pretty strong hold between two of these blocks even if a couple of them by contacting the other one or plain iron. It's difficult to pull away them(easy to slide however).



Quick Details



Place of Origin Sichuan, China (Mainland), Sichuan, China (Mainland)
Brand Name Joint-Mag
Model Number Various accordng to the drawins, Permanent
Type Permanent, Starter Parts
Composite Ferrite Magnet
Shape Magnet Tile, Arc, Segment,Block,Sheet,other according to your requirements
Application Industrial Magnet
Size According to customer's requirements
Car Make Automobile Staters
Name Ferrite
Color Charcoal gray



Specifications

1. Permanent Ferrite Magnet
2. JC-Y4350, FB5H...
3. Annual Capacity: 5000/T.
4, Excellent service



Detailed Product Description


1. Strong SrO·6Fe2O3 Magnet with high quality
2. Custom-made dimension
3. Reasonable price
4. Certificate: ISO9001: 2000



GRADE Br Hcb Hcj (BH)max
T Gs KA/m Oe KA/m Oe KJ/m3 MGOe
JC-Y3932 0.375-0.400 3750-4000 230-275 2890-3456 235-290 2950-3645 26.5-31.5 3.33-3.96
JC-Y3939 0.380-0.400 3800-4000 255-290 3200-3645 260-325 3260-4080 26.5-31.8 3.33-4.00
JC-Y4041 0.390-0.415 3900-4150 260-300 3260-3770 300-350 3770-4400 27.0-32.0 3.39-4.02
JC-Y4127 0.400-0.420 4000-4200 180-225 2260-2825 185-228 2320-2865 30.0-33.6 3.77-4.22
JC-Y4231 0.410-0.430 4100-4300 220-260 2765-3265 255-270 2825-3390 31.5-35.5 3.95-4.46
JC-Y3849 0.370-0.400 3700-4000 271-305 3405-3830 370-400 4650-5025 26.0-31.2 3.27-3.92
JC-Y4240 0.410-0.430 4100-4300 285-314 3580-3945 306-340 3845-4270 31.5-34.4 3.95-4.32
JC-Y4545 0.440-0.460 4400-4600 310-354 3895-4445 346-375 4350-4710 36.5-39.5 4.59-4.96
JC-Y4350 0.420-0.440 4200-4400 295-325 3700-4080 382-410 4800-5150 33.5-36.5 4.21-4.59

Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949 0Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949 1Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949 2Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949 3

Packaging & Delivery

Packaging Details: Carton Wood Pallet
Special Package according to your requirements

Delivery Detail: 10 -40 dyas or according to the order



Company Introduction

Our company is certificated by ISO/TS 16949: 2002 quality system, meanwhile we are a member organization of National Standarlized Technical Committee of magnetic components and ferrite materials, joint-mag is leading the development of the industry and has become one of the most powerful professional manufacturers of permanent ferrite products through continuous technological progress and equipment upgrade.

Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949 4Industrial Permanent Ferrite Bar Magnets Corrosion Proof ISO/ TS16949 5
