Ceramic Processing Permanent Ferrite Magnet Brushless DC Motor Permanent Magnet

Materials
Permanent ferrite magnet is made of SrO. 6Fe2O3 and other microelements by ceramic processing.
Strontium ferrite powders have been designed to produce all grades of hard ferrites. High quality is made by adding proper additives into the powders. Strict quality control system ensure that the quality is stable and reliable.



Brand Name	JOINT-MAG
Type	Magnet Tile
Composite	Ferrite Magnet
Name	Permanent magnet
Shape	Segment; Arc
Color	Charcoal gray
Composite	Ferrite magnet
Shape	Sheet
Packaging Details	Carton Wooden Pallet
Delivery Time	According to the order
Grade	JC-Y3932; JC-Y3939; JC-Y4041; JC-Y4127; JC-Y4231; JC-Y3744; JC-Y3849; JC-Y4240 etc...M

Packaging & Delivery
Packaging Details Carton, box, pallet. Delivery Time Per your order
Specifications
Permanent Ferrite Magnet.
JC-Y4350, FB9H...
Annual Capacity: 5000/T...
ISO/TS: 16949: 2009.
Name: Ferrite tile
Size: Customer made

Product styles available: Arc, Segment

Agnetic property
Br can reach 430 mT Hcb can reach 310 KA/m,
Hcj can reach 395 KA/m (BH)max can reach 3.6 kJ/m3

Size
Provide various dimensions of magnets according to your drawings or samples. Size of Arc magnet includes inner radius, chord length, axis height, harc height

Intelligence Honor
In October 2004, It was conferred with High-tech Product Certificate, awarded as a High-tech Enterprises in Sichuan. By Sichuan Provincial Science and Technology Department in December 2004, and First Price of Sichuan SME Technology Innovation Award In December 2004. In July 2004, our new JC-Y4240 performance (equivalent to Japan S TDK FN6B performance level) of ferrite permanent technology was identified and approved by the experts from Science and Technology Department of the Sichuan Province. The declared High Performance Ferrite Permanent Magnet (JC4545)has been listed among Key Science and Technological Program of Sichuan Province and has been given financial support. In 2007, Technology of manufacturing high-performance ferrite permanent magnet with YF30 pre-sintering materials Were awarded with the tile of Outstanding Technical Achievements and Outstanding Products by the National Materials and Devices industry associations.
