Quick Details
Place of Origin: Sichuan, China (Mainland), Sichuan, China (Mainland)
Brand Name: Joint-Mag, Joint-Mag
Model Number: Various accordng to the drawins, Magnet Tile
Composite: Ferrite Magnet
Application: Industrial Magnet
Size: According to customer's drawing
Car Make: Injection starter magnet
Name: Joint-Mag Ferrite Magnet
Color: Charcoal gray
| Magnet info | |
| Materials | Ferrite |
| Type | Permanent, Injection Ferrite Magnet |
| Shapes | Magnet Tile, Arc, Tile, other according to your requirements |
| Size | Length x Width x Thickness You could choose freely according to your plan. |
| Certificate | IATF 16949 |
| Quality | Our expert quality control department ensures magnets are high quality. |
| Applications | Household application, Industrial application…. |
Packaging & Delivery
Packaging Details: Carton Wood Pallet
Special Package according to your requirements
Delivery Detail: 10 -40 dyas or according to the order
Specifications
1. Permanent Ferrite Magnet
2. JC-Y4350, FB5H...
3. Annual Capacity: 5000/T.
4, Excellent service
Detailed Product Description
1. Strong SrO·6Fe2O3 Magnet with high quality
2. Custom-made dimension
3. Reasonable price
4. Certificate: ISO9001: 2000
Permenant Ferrite Magnets for sale
Ferrite Magnets' outstanding properties
1) High performance:
JC-Y3932; JC-Y3939; JC-Y4041; JC-Y4127; JC-Y4231; JC-Y3744; JC-Y3849; JC-Y4240 JC-Y4350 etc (The grade like JC-Y4350&JC-Y3849, JC-Y4240could meet requirements on strong power).
|
GRADE |
Br |
Hcb |
Hcj |
(BH)max |
||||
|
T |
Gs |
KA/m |
Oe |
KA/m |
Oe |
KJ/m3 |
MGOe |
|
|
JC-Y3932 |
0.375-0.400 |
3750-4000 |
230-275 |
2890-3456 |
235-290 |
2950-3645 |
26.5-31.5 |
3.33-3.96 |
|
JC-Y3939 |
0.380-0.400 |
3800-4000 |
255-290 |
3200-3645 |
260-325 |
3260-4080 |
26.5-31.8 |
3.33-4.00 |
|
JC-Y4041 |
0.390-0.415 |
3900-4150 |
260-300 |
3260-3770 |
300-350 |
3770-4400 |
27.0-32.0 |
3.39-4.02 |
|
JC-Y4127 |
0.400-0.420 |
4000-4200 |
180-225 |
2260-2825 |
185-228 |
2320-2865 |
30.0-33.6 |
3.77-4.22 |
|
JC-Y4231 |
0.410-0.430 |
4100-4300 |
220-260 |
2765-3265 |
255-270 |
2825-3390 |
31.5-35.5 |
3.95-4.46 |
|
JC-Y3849 |
0.370-0.400 |
3700-4000 |
271-305 |
3405-3830 |
370-400 |
4650-5025 |
26.0-31.2 |
3.27-3.92 |
|
JC-Y4240 |
0.410-0.430 |
4100-4300 |
285-314 |
3580-3945 |
306-340 |
3845-4270 |
31.5-34.4 |
3.95-4.32 |
|
JC-Y4545 |
0.440-0.460 |
4400-4600 |
310-354 |
3895-4445 |
346-375 |
4350-4710 |
36.5-39.5 |
4.59-4.96 |
|
JC-Y4350 |
0.420-0.440 |
4200-4400 |
295-325 |
3700-4080 |
382-410 |
4800-5150 |
33.5-36.5 |
4.21-4.59 |
2) High working temperature:
The JC-Y4350 series with 4800-5150 Oe super-high coercive force can replace NdFeB magnets with much lower price.
3) High consistency:
The Br and Hcj of surface magnetic field and magnetic flux can be controlled with +/-1%.
4) High Anti-corrosion:
The sale spray test and humid heat test of the high anti-corrosion coating could be more than 800 hours
5) Low weight loss
The average low weight loss is less than 10 mg/cm2 in 20 days.
Pros: Pretty strong hold between two of these blocks even if a couple of them by contacting the other one or plain iron. It's difficult to pull away them(easy to slide however).
Company Introduction:
Our company is certificated by ISO/TS 16949: 2002 quality system, meanwhile we are a member organization of National Standarlized Technical Committee of magnetic components and ferrite materials, joint-mag is leading the development of the industry and has become one of the most powerful professional manufacturers of permanent ferrite products through continuous technological progress and equipment upgrade.
Sincerely welcome to visit our factory.
Samples are available for your test.
